Product Details:
Payment & Shipping Terms:
|
| Recording Mode: | Auto,motion,segment | Shells: | Mg - Al Alloy |
|---|---|---|---|
| Sensor: | 1/3" CMOS | SD Card: | SD / TF (not Included) |
| High Light: | 4 Camera Security System With DVR And Monitor,Four Camera DVR Security System |
||
black color quad image 4 camera DVR security system with motion detection
Specifications:
|
General specifications for Monitor |
|
| Model number | SP890 Digital type |
|
Monitor screen |
TFT - LCD 7inch RGB color |
|
Contrast Ratio |
300:1 |
|
Brightness |
300cd/m2 |
|
Operating frequency |
2.4GHz - 2.485GHz digital modulation |
|
Antenna type |
All-directional |
|
Receiving sensitivity |
≤85dB |
|
Speaker output |
80dBA |
|
Power Adapter |
DC 5 V / 1000mA |
|
Working temperature |
-10℃~50℃ |
|
Working humidity |
≤85% |
|
Weight |
425g |
|
Dimension |
190mm(L)*140mm(W)*20mm(H) |
|
General specifications for Camera |
|
|
Sensor type |
1/3" CMOS image sensor |
|
Focal length |
4.0mm |
|
Resolution |
H:800 x V:480 |
|
Camera Lens |
American OV lens |
|
Number of Color |
130Mega pixels |
|
IR LED type |
24pcs of IR LED 850nm/8-10m |
|
Transmission Distance |
Min.100 meters,line of sight |
|
Camera material |
Mg-Al alloy |
|
Power Adapter |
DC 5 V / 1000mA |
|
Weight |
188g |
|
Dimension |
57*mm(D)*118mm(H) |
Description:
black color quad image 4 camera DVR security system with motion detection
Some clients bought this DVR for multiple usage.due to it support up to 4 cameras,they can set 1 camera for front yard, 1 camera for baby,or pets,elder, 1 for garage.etc.
Features:
(1). This digital wireless DVR security systems is comply with FCC rules,it has high interference resistance and don't interfere other digital devices.
(2). Fast and wide transmission bandwidth up to 3M in the channel of ISM 2.4GHz - 2.485GHz,match with top - rated MCU control,smooth video display is achieved,as must as 30 fps. (frames per sec )
(3). High resolution: 800 (Horizontal) x 480 (Vertical),high brightness: 300cd/m2,high contrast ratio: 300:1 in a 7-inch area,more clear,more brighter,full color,to compose a professional and portable monitor.
(4). 7-inch TFT LCD display with integrated video recorder.
(5). FHSS tech:auto frequency hopping in different channels to avoid data crowd,all data is encrypted,no privacy leak.
(6). Video quality :4 - CH, 10 fps, and 1 - CH, 30 fps.
(7). Outdoor camera with metal shell and built-in micro-phone,300m/990ft transmission range.
(8). Up to 4 Cams/24hrs/7days,all-weather,never stop,overwrite recording/ different recording modes are optional.
(9). Support external SD/TF card,Max 32GB.
(10). 10 - 15 meters night - vision range.
(11). Video output function for bigger monitor.
Package includes :
1 x Monitor
4 x Cameras (already paired,factory default)
5 x Adapters
1x Suction cup
1 x User manual
Applications for :
| General purpose for all occasions | |
|
Business |
supermarket,offices,shopping malls,drug store,chain shops, home hotels, restaurants, retail store,pharmacy,post offices |
|
Public Places |
book stores, parks, exhibition halls,convention centers, ticket agencies, |
|
Entertainments |
Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, |
Frequently asked questions ( FAQ ) :
1. How to add extra camera to the system with 2 cameras now?
If you buy 2 cameras with monitor as one set, sometimes you want to add extra camera to the system, be sure to buy the same camera from the same factory, otherwise it will not work. Read user manual before operation for " pairing " , when gets in the menu of pairing, press “pairing” on the screen, meanwhile press the button on the connector of the camera, you can see the video from the camera immediately.
2. Why can’t I listen to the sound ?
You can’t listen any sound when in quad image monitoring,you need to choose certain channel to hear the sound from camera,be sure the sound of camera is not mute.
3. Will all the recorded audio video be lose when the power is off unexpected?
Before recording,we recommend to choose segment recording mode in the option of Motion Rec. 5s or 10s for every recording segment,so when the power off, you will lose very few data.
4. Can I use other adapter for the system?
Not recommended.The adapters included with the system are customized to meet 7/24 time’s working after strict quality test and aging test, safety and reliable to system and people.
5. Do you accept small orders like 5pcs, 10pcs or drop shipping?
Yes, no problem. We keep stock for about 50 sets for each model, which can be as samples for customers or for small orders. the unit price will be also competitive in small order or drop shipping.
6. Can you accept OEM or ODM order?
That’s welcomed. Believe in our R & D team, you will satisfied with the product which you expected
For more question,please contact with us freely at sales@seepower.cc.
Why Choose Us :
Our team:
1. The boss is a senior engineer from Foxconn.also the CEO.
2.Engineer team composed by experienced software and hardware engineer for more than 5-8 years in this field.
3. Experienced sales are ready to answer your questions about consulting,sales service orders,technical support,etc. all of them with more than 3-5 years exporting experiences.
Our products:
1.Follow the procedure of optimized scheme priority.before selling new product to the market,several schemes have to be filtered and only 1 scheme is settled and to start small volume production test.
3.To assure quality,main electronic parts and chip sets are imported from Taiwan,Korea, and USA. then adopts nearly 99.9% SMT technology,along with strict QC control. in this way,bring us lower defective rate, lower labor cost, shorter lead time,to achieve the aim of good quality in relatively lower cost.
4. Development & innovation is never stopped. not only to improve current products every year,but to upgrade to a new version of product as well. Master the trend,master the market.
Our service:
1.Free training and consulting,quick response.
2. Always keep stock for fast delivery.
3. Low MOQ to meet different levels of customers.
4. Accept OEM,ODM from product function to packaging.
5. Limited quality warranty for 1 year,free exchange for defective product within 1 year (except human factors).
Our aim:
1. Insist on offering more cost - effective, stable, experienced & mature products for clients. To minimize & save the cost for some aspects including after - sale service.
2. Stick to the policy of clients utmost, quality first.We share this technological products with our clients to bring activation to their market and to help them keep competitive.
