P2P Network 4 Channel DVR Security Camera High Resolution With Real Time

Certification
China China Camera Systems Online Marketplace certification
China China Camera Systems Online Marketplace certification
Customer Reviews
Very appreciate for your professional service & higher standard quality control,very happy to know you.

—— Mr Johnifere

We trust the quality of your products. It always the best. Keep this going, and we will establish a long-term trade relationship with you.

—— Mr Zero

Excellent quality and fast delivery.

—— Victor

I'm Online Chat Now

P2P Network 4 Channel DVR Security Camera High Resolution With Real Time

P2P Network 4 Channel DVR Security Camera High Resolution With Real Time
P2P Network 4 Channel DVR Security Camera High Resolution With Real Time

Large Image :  P2P Network 4 Channel DVR Security Camera High Resolution With Real Time

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Cayera
Certification: CE, FCC
Model Number: AHR-AP104
Payment & Shipping Terms:
Minimum Order Quantity: 200
Delivery Time: 1-4 weeks after get the full payment
Payment Terms: T/T 100% before shipment
Supply Ability: 50000 pcs/per year
Detailed Product Description
Video Frame: PAL:1~25FP/S;NTSC:1~30FP/S Coding Resolution: 4CH 720P(1280x720)
Transmission Distance: 500 Meters USB: Support 2pcs USB Port
Storage: Mobile Hard Disk / U-Hard-Disk / Network Remote Control: With Remote Control
High Light:

analog hd dvr

,

analog digital video recorder

P2P Network 4 Channel DVR Security Camera High Resolution With Real Time





Application:


    Analog AHD DVR can be real-time monitoring, mobile detection, the picture is clear, at the same time with mobile phone remote monitoring function, easy to understand the status of the monitored area anytime and anywhere.

    Using to Family,The school,Bank,The factory,The parking lot,Square,Shopping center,The airport,The bus station,The supermarket,Prison,Office Building,The meeting,Park,Chemical,Oil,Mine,Community,Railway Stations.



Product Features:

  1. H. 264 Video Standard and G. 711 Audio standard
  2.  Support 720P HD preview, recording and playback;
  3. Analog video transmission technology, coaxial cable as the transmission medium; Coaxial two-way data Cable send control signals such as head rotation, zoom control, etc;
  4. Transmission over long distances, 720P via 75-3 coaxial, ensures transmission of 500-meter HD video signals;
  5. Anti-interference ability, under strong interference environment ensure the transmission of high-definition video display, distortion does not occur, dropped frames;
  6. Apply a new UI, more intuitive and simple user experience using the menu style 3 full display
  7. Video features: Manual recording, timer recording, motion detection etc; USB interface backup and network backup - support CVBS, VGA and HDMI output simultaneously, VGA, HDMI Full 1080P, to overturn traditional monitor display



SPECIFICATIONS



Performance Parameters

Sensor

Main Board Sensor

Industrial Embedded Microprocessor

Operating System

Embedded LINUX operating system

System

Video Coding

H.264

Coding Resolution

4CH 720P(1280x720)

Video Frame

PAL:1~25FP/S;NTSC:1~30FP/S

Video Bit Rate

512Kbps-4096Kbps,Customizable,Default to be 2048Kbps

Stream Type

Video Streaming / Composite Stream

Double Stream

Support

Audio Coding

G.711

Audio Sampling rate

8KHz,16Bit

Audio Bit Rate

64Kbps

Video Spec

Video Input

4CH BNC Port

Video output

1CH CVBS,1CH VGA output,1CH HDMI port

Recording Manage

Recording Mode

Automatic recording, Manual Recording, Motion Detection

Recording, Alarm Recording

Playback

4CH Playback

Backup Mode

Mobile Hard Disk / U-Hard-Disk / Network

Network

Protocol

Support TCP/IPUDPRTP/RTSPDHCPPPPoEDDNSNTP etc.

IE Control

With WEB Server to modify configuration parameters

and remote control IE

P2P Cloud

Support login via www.yunyis.com to meet One-Key Remote Control.

Mobile Remote

Support IOS, Android,Blackberry, Symbion, Software .

HDD

HDD Port

Support 1SATA port max 4TB,No e-SATA port.

Interface

Network/USB

1 RJ45 port, 100M E-internet Port ; 2PCS USB Port

Interface

1PC Standard RJ485 port

Others

Power/Consumption

DC12V  ; less than15W(No HDD)

Temperature/Humidity

Temperature:-10deg-+55deg/  Humidity: 10%~90%
